WifiScanner: include.h File Reference

"Call with no parameters or with the following options\n" \
" --help          -h           - This help page\n" \
" --version       -v           - Write Version and quit\n" \
" --verbose       -V level     - For verbose, level 2 is for debugging\n" \
" --card-driver   -C           - Wireless card driver :\n" \
"                                'prism', 'cisco' 'cisco_wifi (eth+wifi)' 'orinoco' 'atheros', 'prism54g', or 'hostap'\n" \
" --iface         -i device    - Name of the interface (default wlan0)\n" \
"                              - for cisco_wifi driver, give the two interfaces like eth1,wifi0\n" \
" --output-file   -F filename  - Save output to a file as well as stdout\n" \
" --device-file   -D filename  - Create a file of detected devices, in a .dot format\n" \
" --hop           -H number    - Number of hops do for rotating channel (default 5)\n" \
" --channel       -S channel   - Only listen on a specific Channel (1-14)\n" \
" --computer-date -d           - Write date in machine readable format\n" \
" --ids           -I           - Activate the IDS functions\n" \
" --max-packets   -M number    - Max packets to capture before exit\n" \
"                                (0 = unlimited)\n" \
" --hide-packets  -N abcd      - Do not display Ack, Beacon, Control, Data\n" \
" --hop-delay     -t number    - Number of ms before channel change (default=200)\n" \
" --disable-check -c           - Do not chek curses screen size\n" \


Data Structures
struct	p80211_caphdr
Defines
#define	LWNG_16
#define	LWNG_15
#define	LWNG_14
#define	ABSTRACTION_LAYER
#define	FALSE (UINT8) 0
#define	TRUE (UINT8) 1
#define	UINT8_MAX (0xffUL)
#define	UINT16_MAX (0xffffUL)
#define	UINT32_MAX (0xffffffffUL)
#define	INT8_MAX (0x7fL)
#define	INT16_MAX (0x7fffL)
#define	INT32_MAX (0x7fffffffL)
#define	__WLAN_ATTRIB_PACK__ __attribute__ ((packed))
#define	__WLAN_PRAGMA_PACK1__
#define	__WLAN_PRAGMA_PACKDFLT__
#define	__WLAN_INLINE__ inline
#define	WIFISCANNER_VERSION WIFISCANNER_VERSION_NUM
#define	MAX_BUFFER_SIZE 4096
#define	DEVNAME_LEN 16
#define	MCAST_GRP_SNIFF 0x00000002
#define	WLAN_STR_ADDR_LEN 18
#define	MAXSIZE_OTHERINFORMATION 0x100
#define	HISTORY_SIZE 4
#define	MAX_NUMBER_OF_DETECTED_CLIENT 8192
#define	KEYBOARD_BUFFER 8
#define	MANUF_MAXSTRINGLENGTH 32
#define	TIME_TO_SLEEP_BEFORE_CHANGE_CHANNEL (1000/(14*1))
#define	TIMEOUT_TRY_TO_READ_PAQUET (1000000/(14/2))
#define	SET_BIT(a, n) (a\|=(1<<n))
#define	CLR_BIT(a, n) (a&=~(1<<n))
#define	IS_BIT_SET(a, n) (a & (1<<n))
#define	IS_BIT_CLR(a, n) (~(a & (1<<n)))
#define	SWITCH_BIT(a, n) (a^=(1<<n))
#define	GET_BIT(a, n) ((a >> n) & 1)
#define	TYPE_BIT_AP 0
#define	TYPE_BIT_BEACON 1
#define	TYPE_BIT_P2P 2
#define	TYPE_BIT_DATA 3
#define	TYPE_BIT_TODS 4
#define	TYPE_BIT_FROMDS 5
#define	SET_TYPE_BIT_AP(x) SET_BIT(x, TYPE_BIT_AP)
#define	SET_TYPE_BIT_BEACON(x) SET_BIT(x, TYPE_BIT_BEACON)
#define	SET_TYPE_BIT_P2P(x) SET_BIT(x, TYPE_BIT_P2P)
#define	SET_TYPE_BIT_DATA(x) SET_BIT(x, TYPE_BIT_DATA)
#define	SET_TYPE_BIT_TODS(x) SET_BIT(x, TYPE_BIT_TODS)
#define	SET_TYPE_BIT_FROMDS(x) SET_BIT(x, TYPE_BIT_FROMDS)
#define	CLEAR_TYPE_BIT_AP(x) CLR_BIT(x, TYPE_BIT_AP)
#define	CLEAR_TYPE_BIT_BEACON(x) CLR_BIT(x, TYPE_BIT_BEACON)
#define	CLEAR_TYPE_BIT_P2P(x) CLR_BIT(x, TYPE_BIT_P2P)
#define	CLEAR_TYPE_BIT_DATA(x) CLR_BIT(x, TYPE_BIT_DATA)
#define	CLEAR_TYPE_BIT_TODS(x) CLR_BIT(x, TYPE_BIT_TODS)
#define	CLEAR_TYPE_BIT_FROMDS(x) CLR_BIT(x, TYPE_BIT_FROMDS)
#define	GET_TYPE_BIT_AP(x) GET_BIT(x, TYPE_BIT_AP)
#define	GET_TYPE_BIT_BEACON(x) GET_BIT(x, TYPE_BIT_BEACON)
#define	GET_TYPE_BIT_P2P(x) GET_BIT(x, TYPE_BIT_P2P)
#define	GET_TYPE_BIT_DATA(x) GET_BIT(x, TYPE_BIT_DATA)
#define	GET_TYPE_BIT_TODS(x) GET_BIT(x, TYPE_BIT_TODS)
#define	GET_TYPE_BIT_FROMDS(x) GET_BIT(x, TYPE_BIT_FROMDS)
#define	TYPE_BIT_00 "Client"
#define	TYPE_BIT_01 "AP Base"
#define	TYPE_BIT_02 "AP Base (STA in master mode)"
#define	TYPE_BIT_03 "AP Base (dedicated)"
#define	TYPE_BIT_04 "Ad-Hoc STA"
#define	TYPE_BIT_05 "???5"
#define	TYPE_BIT_06 "Ad-Hoc STA (beacon)"
#define	TYPE_BIT_07 "Ad-Hoc STA"
#define	TYPE_BIT_08 "STA Activity"
#define	TYPE_BIT_09 "???9 Reserved"
#define	TYPE_BIT_0A "???A Reserved"
#define	TYPE_BIT_0B "???B Reserved"
#define	TYPE_BIT_0C "???C Reserved"
#define	TYPE_BIT_0D "???D Reserved"
#define	TYPE_BIT_0E "???E Reserved"
#define	TYPE_BIT_0F "???F Reserved"
#define	SUBTYPE_BIT_00 "Radio only"
#define	SUBTYPE_BIT_01 "Data To DS"
#define	SUBTYPE_BIT_02 "Data From DS"
#define	SUBTYPE_BIT_03 "Data AP to AP"
#define	SUBTYPE_BIT_04 "???4 Reserved"
#define	SUBTYPE_BIT_05 "???5 Reserved"
#define	SUBTYPE_BIT_06 "???6 Reserved"
#define	SUBTYPE_BIT_07 "???7 Reserved"
#define	SUBTYPE_BIT_08 "???8 Reserved"
#define	SUBTYPE_BIT_09 "???9 Reserved"
#define	SUBTYPE_BIT_0A "???A Reserved"
#define	SUBTYPE_BIT_0B "???B Reserved"
#define	SUBTYPE_BIT_0C "???C Reserved"
#define	SUBTYPE_BIT_0D "???D Reserved"
#define	SUBTYPE_BIT_0E "???E Reserved"
#define	SUBTYPE_BIT_0F "???F Reserved"
#define	WLAN_SIZEOF_TYPEOFPACKET 6
#define	STR_YES "Yes"
#define	STR_NO "No"
#define	STR_WEP "Wep"
#define	STR_NOWEP "---"
#define	STR_STA "STA"
#define	STR_AP "AP"
#define	MAX_DEBUG_LEVEL 3
#define	DEBUG_POINT debug(3, "%s:%d\n", __FUNCTION__, __LINE__);
#define	HELPTEXT1
#define	HELPTEXT
#define	IS_DISPLAY_ACK(x) ( (x > 0) & 1)
#define	IS_DISPLAY_BEACON(x) ( (x > 1) & 1)
#define	IS_DISPLAY_CONTROL(x) ( (x > 2) & 1)
#define	IS_DISPLAY_DATA(x) ( (x > 3) & 1)
#define	WLAN_NG_CARD 1
#define	CISCO_CARD 2
#define	LUCENT_CARD 3
#define	WLAN_NG_CARD_AVS_CFF2 4
#define	PCAP_VIRTUAL_CARD 5
#define	HOSTAP_CARD 6
#define	CISCO_CVS_CARD 7
#define	ATHEROS_CARD 8
#define	PRISM54G_CARD 9
#define	phytype_fhss_dot11_97 1
#define	phytype_dsss_dot11_97 2
#define	phytype_irbaseband 3
#define	phytype_dsss_dot11_b 4
#define	phytype_pbcc_dot11_b 5
#define	phytype_ofdm_dot11_g 6
#define	phytype_pbcc_dot11_g 7
#define	phytype_ofdm_dot11_a 8
#define	WLAN_ETHADDR_LEN 6
#define	WLAN_IEEE_OUI_LEN 3
#define	WLAN_ETHCONV_ENCAP 1
#define	WLAN_ETHCONV_RFC1042 2
#define	WLAN_ETHCONV_8021h 3
#define	WLAN_MIN_ETHFRM_LEN 60
#define	WLAN_MAX_ETHFRM_LEN 1514
#define	WLAN_ETHHDR_LEN 14
#define	WLAN_SSID_MAXLEN 32
#define	P80211CAPTURE_VERSION 0x80211001
Typedefs
typedef p80211_caphdr	p80211_caphdr_t
typedef CaptureArg_t	CaptureArg

include.h File Reference

Data Structures

Defines

Typedefs

Define Documentation

Typedef Documentation
